XGS-PON Filter optical receiver 1270/1577+1550nm +1310/1490)


Description Features Parameter Model Preview Download

Fiber to the home broadband access is the ultimate development goal, FTTH fitering optical receiver FWR-XGS-1000GSD is the target terminal products for this goal. It selects low optical power receiving and RF technique which can achieve the requirement of FTTH that CATV & GPON, 10GPON, XGPON, XGSPON, NGPON2, GEPON, Ethernet PtP & Wavelength multiplexing of CATV RF in FTTH xPON networks receiving 1550nm wavelength in CATV signal.

FWR-XGS-1000GSD is provided with the optical power receiving monitoring indicator LED on the panel≥-15dBm).“FWR-XGS-1000GSD”means the function of filtering.


 PIN optical receiving power, -1dBm receiving sensitivity, AGC receiving range: -2 ~ -12dBm, output stable level: 82dBuv.

◆  Wide bandwidth type: 47 ~ 1000MHz working bandwidth.

◆  One fiber can receive long-range CATV RF signal and filter out XGS-PON(1310/1490 & 1270/1577nm) signal that has an effect on CATV signal.

◆  It can be used along with the FULLWELL optical transmitter and XGS-PON & CATV WDM EDFA for FTTH triple play transmission and coverage.

◆  Industry-leading 5V power adapter, non-stop work design for more than 5 years.

◆ Can be compatible with any FTTx XGS-PON triple play optical network.

◆  Black plastic enclosure, exquisite texture appearance, to demonstrate brand strength.



Item

Unit

FWR-XGS-1000GSD

Optical  characteristic

input wavelength

nm

1310/1490,1270/1577,1550

operation wavelength

nm

15401560

responsivity

(A/W)

≥0.9

receive power range

dB

+2-18

reflection loss

dB

≥50

fiber linker

/

SC/APC

RF characteristic

bandwidth/flatness

MHz/dB

451000

output level

dBuv

82±1.5AGC: -2~-12dBm

reflection loss

dB

≥14characteristic impedance75Ω

RF output impedance

Ω

75(RF Output Interface Metric F)

MER

(Closed Equalization)

dB

25(64QAM)

31(256QAM)

MER

(Open Equalization)

dB

32(64QAM)

34(256QAM)

Bit Error Rate(BER)

/

≤1×10-4

CNR/CTB/CSO

dB

≥43/≥54/≥54(-9dBm/Nominal Level)

Others

Power Supply/Consumption

V/W

External AC90~255VDC5/2

Working/Storage Temperature

-25~55 / -40~75

Working/Storage Humidity

%

5~90(No Condensation)

size

mm

90×60×22



FWR-XGS-1000GSD,  XGS-PON & CATV Filter Optical Receiver

FWR-1000GSD,           PON & CATV Filter Optical Receiver
